Fotodetector con Petición de Imagen Grado 3 Blanco Ajax Superior

Photo Detector with Image on Request Grade 3 White Ajax Superior

Name: Photo Detector with Image on Request Grade 3 White Ajax Superior
SKU: DRT-0022
Price: 318.96 EUR
Availability: InStock

318,96 € VAT incl.

Ajax · Detector with camera · 15 m · Volumetric

I want it installed

Tick it and we’ll send you an installation quote for your area, with a 10% discount for buying the equipment here.

Installation area

The 10% applies to the total installation quote (labour and materials), provided the installation is requested within 6 months of the purchase and in one of the areas listed. Offer valid until withdrawn.

How much would it cost? Area not listed? Ask us, no commitment:

Call WhatsApp

Free shippingacross Spain
Official warrantymanufacturer
100% secure paymentcard & wallets
We sell & installCosta del Sol

SKU: DRT-0022 Category: Outdoor Detectors

Description

Photo Detector with Image on Request Grade 3 White Ajax Superior is a wireless detector (Superior series). It features certification Grade 3 and power supply 4 batteries CR123A 3.0 V Duracell Procell.

Highlights

Series: Superior
Security grade: Grade 3
Communication protocols: 868 MHz Superior Jeweller and TurboWings
Transmission distance: ≤ 3500 m in open space
Firmware update: Available. Remote OTA (over-the-air) updates
Technology: Volumetric PIR with HD camera
Detection field: 15 m / H: 90º / V: 71º
Recommended installation height: 2.4 meters
Sensitivity: Adjustable. 3 levels (bajo, medio and alto)
Detection speed: From 0.1 a 4.0 m/s
False-alarm prevention: SmartDetect software algorithm
Temperature compensation: -10º C ~ +40º C
Pet immunity: Not available
HDR technology: Available. Improves detail accuracy in bright and dark scenes.
IR backlight: Available. Takes photos at night or in low light
Privacy management: End-customer control over image-request permissions
Photo series: 1 to 5 photos per detection
3 sec: resolution 160 × 128 px
4.5 sec: resolution 288 × 240 px
11 sec: resolution 576 × 480 px
15.5 sec: resolution 864 × 720 px
On demand: The user takes photos at any time or when the detector is armed (depending on the configuration)
By scenario: the detector’s camera automatically takes photos when the Ajax fire detectors or any other detector in the system are triggered
By schedule: the detector automatically takes photos at a set time
On arming/disarming: the detector automatically takes photos when the security state changes
Anti-masking: Available. Detects attempts to block the detector’s view
Tamper protection: 2 tamper switches
Locking with mounting bracket: Available. For SmartBracket mounting panel
Power supply: 4 batteries CR123A 3.0 V Duracell Procell
Duration: Up to 6 years
Operating temp.: -10 º C ~ 40 º C
Operating humidity: Up to 75%
Protection rating: IP30, IK04
Dimensions: 140 (H) x 64 (W) x 66.6 (D) mm
Weight: 294 g
Color: White

Additional information

Brand	Ajax
Series	Superior
Security grade	Grade 3
Communication protocols	868 MHz Superior Jeweller and TurboWings
Transmission distance	≤ 3500 m in open space
Firmware update	Available. Remote OTA (over-the-air) updates
Technology	Volumetric PIR with HD camera
Detection field	15 m / H: 90º / V: 71º
Recommended installation height	2.4 meters
Sensitivity	Adjustable. 3 levels (bajo, medio and alto)
Detection speed	From 0.1 a 4.0 m/s
False-alarm prevention	SmartDetect software algorithm
Temperature compensation	-10º C ~ +40º C
Pet immunity	Not available
HDR technology	Available. Improves detail accuracy in bright and dark scenes.
IR backlight	Available. Takes photos at night or in low light
Privacy management	End-customer control over image-request permissions
Photo series	1 to 5 photos per detection
3 sec	resolution 160 × 128 px
4.5 sec	resolution 288 × 240 px
11 sec	resolution 576 × 480 px
15.5 sec	resolution 864 × 720 px
On demand	The user takes photos at any time or when the detector is armed (depending on the configuration)
By scenario	the detector's camera automatically takes photos when the Ajax fire detectors or any other detector in the system are triggered
By schedule	the detector automatically takes photos at a set time
On arming/disarming	the detector automatically takes photos when the security state changes
Anti-masking	Available. Detects attempts to block the detector's view
Tamper protection	2 tamper switches
Locking with mounting bracket	Available. For SmartBracket mounting panel
Power supply	4 batteries CR123A 3.0 V Duracell Procell
Duration	Up to 6 years
Operating temp.	-10 º C ~ 40 º C
Operating humidity	Up to 75%
Protection rating	IP30, IK04
Dimensions	140 (H) x 64 (W) x 66.6 (D) mm
Weight	294 g
Color	White
